Name: V-Solution 10G 4-Port EPON OLT | V1600D4-DP
Availability: InStock

V-Solution 10G 4-Port EPON OLT | V1600D4-DP

V-Solution 10G 4-Port EPON OLT | V1600D4-DP

| 0 Ratings

৳38,000 -5%

Regular Price: ৳40,000

Brand: V-Solution
Model: V1600D4
EPON Port: 1:64 Splitting Ratio
4x10G SFP+ Slots, (SFP+ is 10GE Port)
Warranty: 2-Year Warranty

In Stock

VARIATION

38000

- +

V-Solution 10G 4-Port EPON OLT | V1600D4-DP:

Model: V1600D4-DP Spec: 4*EPON, 4GE(RJ45)+4*10GE(SFP+) Dual power modules available in DC/AC Weight: 3.2kg

Item		V1600D4-DP
Chassis	Rack	1U 19-inch standard box
1000M Uplink Port	QTY	8
	Copper	4*10/100/1000M auto-negotiation
	SFP (independent)	4SFP or 4SFP+ slots, (SFP+ is 10GE)
EPON Port	QTY	4
	Physical Interface	SFP Slots
	Connector Type	1000BASE-PX20+
	Max splitting ratio	1:64
Management Ports		110/100BASE-Tout, band port, 1CONSOLE port
PON Port Specification	Transmission Distance	20KM
	EPON port speed	Symmetrical 1.25Gbps
	Wavelength	TX 1490nm, RX 1310nm
	Connector	SC/PC
	Fiber Type	9/125μm SMF
	TX Power	+2~+7dBm
	Rx Sensitivity	-27dBm
	Saturation Optical Power	-6dBm

Function:

Management Mode	SNMP, Telnet, and CLI
Management Function	Fan Group Detecting; Port Status monitoring and configuration management; Layer2 switch configuration such as VLAN, Trunk, RSTP, IGMP, QOS, etc; EPON management function: DBA, ONU authorization, ACL, QOS, etc; Online ONU configuration and management; User management; Alarm management.
Layer2 Switch	Support port VLAN and protocol VLAN; Support 4096 VLANs; Support VLAN tag/Un-tag, VLAN transparent transmission, QinQ; Support IEEE802.3d trunk; Support RSTP; QoS based on port, VID, TOS, and MAC address; IGMP Snooping; IEEE802.x flow control; Port stability statistic and monitoring.
Layer 3 Route	1024 Host Routes; 512 Subnet Routes; 256 IP Multicast Groups;
EPON Function	Support port-based rate limitation and bandwidth control; In compliant with IEEE802.3ah standard; Up to 20KM transmission Distance; Support data encryption, multi-cast, port VLAN, Support ONU auto-discovery/Link detection/remote upgrade of software; Support VLAN division and user separation to avoid the broadcast storm

Physical Specification:

Dimension(LWH)		442mm200mm43.6mm
Weight		4.2kg
Power Supply	220VAC	AC:90~264V, 47/63Hz	Double Hot Backup
Power Consumption		30W
Operating Environment	Working Temperature	-10~+55℃
	Storage Temperature	-40~+85℃
	Relative Humidity	5~90%(non-conditioning)

What is the price of the V-Solution 10G 4-Port EPON OLT | V1600D4-DP in Bangladesh?

The latest price of the V-Solution 10G 4-Port EPON OLT | V1600D4-DP in Bangladesh is 38,000৳. You can buy the V-Solution 10G 4-Port EPON OLT at the best price from our website or visit our showroom. Stay connected with our what's Page or Facebook Page.
